HVS Series Vertical Shaft Impact Crusher
It is widely used in shaping and artificial sand making in the production of sand and gravel aggregates, and can also be used in the fine crushing of mines and aggregate. The grading of various aggregates can be realized by adjusting the central feeding and overflow volume and the rotor speed to meet the requirements of various specifications of the finished productss.
Inquiry
- Crushing Of High-quality Finished Products
The principle of stone crushing is adopted. The materials collide with each other. The finished product has good particle shape, low needle and sheet content and low wear cost. - Easy Installation
Compact structure, low overall height, small operating foundation load, and convenient on-site installation. - Reliable Control System
Compact structure, low overall height, small operating foundation load, and convenient on-site installation. - Simple Maintenance
Dry oil lubrication, simple and reliable, equipped with hydraulic jacking and lifting tools, easy maintenance, greatly improving production efficiency.
TECHNICAL PARAMETERS
| Model | Maximum Feed Size（mm） | Rotor Linear Speed （m/s） | Motor Power （kw） | Equipment Weight（t） |
| HVS7150 | 50 | 45-70 | 264-320 | 13.6 |
| HVS9100 | 60 | 45-70 | 440-630 | 17 |
PROCESSING CAPACITY
| Model | Motor Power （kw） | Corresponding processing capacity of different linear speeds (M / s) (T / h) | |||||
| 45 | 50 | 55 | 60 | 65 | 70 | ||
| HVS7150 | 2×132 | 310 | 275 | 245 | 205 | 185 | 165 |
| 2×160 | 375 | 315 | 285 | 250 | 210 | 190 | |
| HVS9100 | 2×220 | 500 | 450 | 375 | 335 | 305 | |
| 2×250 | 525 | 465 | 395 | 360 | |||
| 2×315 | 600 | 530 | 455 | 410 | |||
